Skirting Duct
PROFILE
LENGTH
SINGLE OUTLET COVER
DOUBLE OUTLET COVER
130mm x 35mm
3m Base, 1.8m Cover
155mm
295mm
COLOURS
Other colours available upon request.
The Contractor shall install a 2 Channel Skirting Duct, SKIRTEC Type 21, with Aluminium / Polymer base and clip fit Polymer cover, as indicated on the tender drawings, 90 degree corners shall be factory made and modular. Base section shall be fixed to the walls at intervals no less than 900mm and the duct system shall be installed in accordance with the manufacturer’s instructions.
PCB21
Skirting duct polymer base & cover, per meter
PK21S
Single outlet kit for 1x DGPO or data plate
PK21D
Double outlet kit for 2x grid plates (Data & GPO)
PIC21
Modular internal corner
PEC21
Modular external corner
PES21
End stop, left or right
